The 12.6 inch Android POS tablet with iMin's swivel barcode imager built in, so the terminal that takes the payment also scans the stock.
This is the Falcon 2 Max with iMin's industrial barcode imager fitted. It reads 1D and 2D codes, it is described by iMin as enterprise class with a wide field of view and a broad working range, and the part that matters day to day is the mount: the scanner swivels through 90 degrees of continuous rotation. That sounds like a small thing until you watch someone try to scan a label on the underside of a heavy box with a fixed camera. Rotate the head instead of the carton and the awkward scans stop being awkward.
Underneath it is the same machine as the rest of the range: a 12.6 inch IPS panel at 2560 x 1600, an octa core processor pairing a dual core Arm Cortex-A76 at 2.2GHz with a hexa core Cortex-A55, Android 13 with Google Mobile Services, in screen NFC for contactless, 4G alongside Wi-Fi 5, and a 10,000 mAh battery that reports its own health. This configuration carries 4GB of RAM and 64GB of storage, which suits a single POS app and the usual back office tools. If you run several heavy apps side by side, look at the 8GB version.
A separate Bluetooth barcode scanner is rarely the end of the cost. It is a second device to buy, a second battery to charge, a second thing to pair when it drops off, and a second thing to replace when it is left on a shelf or dropped. On POS Plaza the gap between this model and the same tablet without the scanner is $100, which is less than most standalone 2D scanners cost on their own. If your staff scan at all, even just for stocktake, the built in imager is usually the cheaper answer as well as the tidier one. The exception is a high volume checkout where someone scans continuously for hours, because a dedicated handheld or presentation scanner is still faster and kinder on the wrist than holding up a 560 g tablet.
Walk the shelves scanning with the same tablet that runs your POS, so counts land straight in the system instead of on paper.
Scan the parcel label, confirm the order and take any balance owing in one pass at the pickup desk.
Scan the barcode, check price and stock on a screen the customer can see, and settle by tap, all on one device.
| Model | iMin Falcon 2 Max, 4GB RAM, 64GB ROM, 4G, 2D scanner |
| POS Plaza SKU | TTIMFALCON2MAX003 |
| Operating system | Android 13, 64 bit, with Google Mobile Services (GMS) |
| Processor | Octa core: dual core Arm Cortex-A76 at 2.2GHz plus hexa core Arm Cortex-A55 at 2.0GHz |
| Memory | 4GB RAM and 64GB ROM |
| Display | 12.6 inch IPS, 2560 x 1600, multi point capacitive touch panel |
| Built in barcode scanner | Yes. Enterprise class 1D and 2D imager on a swivel mount with 90 degree continuous rotation, with a wide field of view and a broad working range |
| Mobile data | 2G, 3G and 4G LTE |
| Wireless | Wi-Fi 5 (802.11 a/b/g/n/ac, 2.4GHz and 5GHz), Bluetooth 5.2, GPS |
| NFC | In screen NFC, no separate reader needed at the counter |
| Cameras | 2 MP front, 13 MP rear |
| Biometrics | Fingerprint unlock |
| Battery | 3.89V, 10,000 mAh, 38 Wh smart battery with real time health monitoring |
| Audio | 1W dual speakers |
| Ports | USB-C x1 (supports OTG), Nano SIM x2, TF card x1, pogo pin connector for docking |
| SIM configuration | Either eSIM plus 1 Nano SIM plus 1 TF card, or 2 Nano SIM plus 1 TF card |
| Buttons | Power, volume up, volume down |
| Docking | Magnetic dock design, works with the Basic Dock, Basic Folding Dock and 80mm Printer Dock |
| Drop rating | 1.0 m drop test for typical use in casual settings |
| Operating temperature | -10 to 50 degrees C |
| Storage temperature | -20 to 60 degrees C |
| Dimensions | 292.80 x 191.55 x 9.50 mm |
| Weight | 560 g |
| Warranty | 12 Months Return to Base |
| 4GB/64GB | 4GB/64GB + 2D, this one | 8GB/128GB | 8GB/128GB + 2D | |
|---|---|---|---|---|
| POS Plaza SKU | TTIMFALCON2MAX001 | TTIMFALCON2MAX003 | TTIMFALCON2MAX002 | TTIMFALCON2MAX004 |
| Price | $1,299 | $1,399 | $1,579 | $1,749 |
| Memory | 4GB RAM, 64GB ROM | 4GB RAM, 64GB ROM | 8GB RAM, 128GB ROM | 8GB RAM, 128GB ROM |
| Built in 2D scanner | No | Yes | No | Yes |
| Display | 12.6 inch, 2560 x 1600 | 12.6 inch, 2560 x 1600 | 12.6 inch, 2560 x 1600 | 12.6 inch, 2560 x 1600 |
| Processor | Octa core A76 + A55 | Octa core A76 + A55 | Octa core A76 + A55 | Octa core A76 + A55 |
| 4G, Wi-Fi 5, BT 5.2, GPS, NFC | Yes | Yes | Yes | Yes |
| Battery | 10,000 mAh | 10,000 mAh | 10,000 mAh | 10,000 mAh |
| Best for | Order taking and payments on a big screen | The same, when staff also scan barcodes | Heavier apps, more local data, longer life | The full configuration |
All four share the 12.6 inch panel, the octa core processor, Android 13 with GMS and the 10,000 mAh battery. The only two variables are memory and the scanner. If the big screen is what appeals but the budget is not there, the iMin Falcon 2 at 10.95 inch runs the same platform in a smaller body.
The scanner is built in, but nothing else is. The Falcon 2 Max attaches magnetically to an iMin dock, which is what lets one tablet be a counter terminal and a floor scanner on the same shift. The docks are separate orders:
Included with this part number:
Not included:
An industrial 1D and 2D imager on a swivel mount that rotates through 90 degrees continuously. iMin describes it as enterprise class, with a wide field of view and a broad working range, and it reads both printed barcodes and QR codes off screens. Note that iMin does not publish the scan engine vendor or model for this unit, so we do not claim one. If you need the exact engine spec for a tender or an integration, ask us and we will get it in writing from the supplier.
Yes, identically so. Same 12.6 inch 2560 x 1600 panel, same octa core processor, same 4GB and 64GB, same Android 13 with GMS, same 4G and Wi-Fi 5 and in screen NFC, same 10,000 mAh battery, same magnetic docking. The scanner is the only difference, and it is $100.
It comes down to how hard your software works the tablet. 4GB and 64GB is comfortable for one POS app plus the usual back office bits. Step up to the 8GB and 128GB model if you run several apps at once, hold a big offline product catalogue on the device, or expect the fleet to still be in service in three or four years as apps get heavier. The gap is $350.
Yes. A 2D imager reads codes off a display as well as off paper, which covers e-vouchers, digital membership cards, click and collect codes and e-tickets. A laser scanner cannot do that, which is one of the reasons the imager is the right choice for retail now.
It draws more than the screen alone, but the 10,000 mAh battery is sized for the whole device with the scanner running. The practical answer is to dock it whenever it is not in someone's hands. Because docking is magnetic, parking it is a one second action rather than a cable, so it tends to stay topped up without anyone thinking about it.
All three iMin Falcon 2 Max docks: the Basic Dock, the Basic Folding Dock and the 80mm Printer Dock. None are included. The printer dock is the one to look at if this is a fixed counter, because it brings an 80mm receipt printer at 250 mm/s with an auto cutter plus a cash drawer port and Ethernet.
Rated to a 1.0 m drop for typical use in casual settings, and it runs from -10 to 50 degrees C. That is a retail floor or a dining room, not a loading dock. If staff will carry it all shift, the protective case with strap is worth the $145.
12 Months Return to Base. Send the unit to us within the warranty period and we deal with iMin on the repair or replacement.
The iMin Falcon 2 Max with 2D scanner (POS Plaza SKU TTIMFALCON2MAX003) is the scanner equipped version of iMin's 12.6 inch Android POS tablet, sold by POS Plaza at $1,399 including GST. Its industrial imager reads 1D barcodes and 2D codes including QR, from printed labels and from phone screens, and sits on a swivel mount offering 90 degree continuous rotation. iMin describes the engine as enterprise class with a wide field of view and a broad working range but does not publish the vendor or model. Memory is 4GB RAM with 64GB ROM. The display is a 2560 x 1600 IPS multi touch panel; the processor is octa core, pairing a dual core Arm Cortex-A76 at 2.2GHz with a hexa core Arm Cortex-A55 at 2.0GHz; the operating system is Android 13, 64 bit, with Google Mobile Services. Radios cover 2G, 3G and 4G LTE, Wi-Fi 5, Bluetooth 5.2, GPS and in screen NFC. The SIM tray takes either an eSIM with one Nano SIM and a TF card, or two Nano SIMs with a TF card. Power is a 3.89V 10,000 mAh 38 Wh smart battery reporting its own health. Also fitted: 2 MP front and 13 MP rear cameras, fingerprint unlock, 1W dual speakers, USB-C with OTG and a pogo pin dock connector. The body is 292.80 x 191.55 x 9.50 mm at 560 g, drop rated to 1.0 m and rated from -10 to 50 degrees C. It is the same tablet as TTIMFALCON2MAX001 with the scanner added for $100, and iMin's docks and protective case are ordered separately. Warranty: 12 Months Return to Base.
Scanning all day at a fixed counter? Ask us whether a presentation scanner suits you better.
