Zebra Scanner Kit DS9308 with 1D, 2D scanning capabilities

SKU: ZCZEDS9308SR4U210011251
Excl.GST: $207.27
Incl.GST: $228.00
36 Months Return to Base

Zebra DS9308 Scanner Kit with 1D, 2D scanning capabilities

  • Compact in size with full functionalities, the Zebra DS9308 Scanner Kit can decode 1D, 2D, Digimarc and OCR barcodes accurately with rapid-fire speed. It is well suited for a diverse range of applications including POS, coupons, retail, hospitality, restaurants, convenience stores, and transportation.
  • A part of the Zebra DS9300 Series of scanners, it has a high-resolution megapixel sensor, an 800 MHz microprocessor, and PRZM Intelligent Imaging technology. The scanner kit comes with a USB interface cable, and can instantly scan barcodes of any quality on any surface. The LEDs automatically adapt by dimming when not in use to prevent eye strain. Durable with a small footprint, this scanner can withstand multiple drops and fit in any environment.
  • If you are looking for a good quality and user-friendly scanner that can scan 1D, 2D barcodes with excellent speed and accuracy, then the Zebra Scanner DS9308 is a good choice.

Key Features & Benefits of Zebra DS9308

  • Scanning Technology: Array Imager
  • Dimensions: 14.5 cm. H x 8.6 cm. W x 8.3 cm. D (5.7 in. H x 3.4 in. W x 3.3 in. D)
  • Weight: 318.0 g / 11.2 oz.
  • Supported Host Interfaces: USB, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485
  • Swipe Speed: Up to 305 cm. /120 in. per second for 13 mil UPC in optimised mode
  • Image Sensor: 1280 x 800 pixels
  • Minimum Print Contrast: 15%
  • Graphics Format Support: Images can be exported as bitmap, JPEG or TIFF
  • Drop Specification: Designed to withstand multiple drops from 1.5 m. / 5.0 ft. to concrete
  • Decode Range: 0 cm /0 in. to 27.9 cm / 11.0 in
  • Symbol Decode Capability: 1D, 2D, OCR, Digimarc
  • Minimum Element Resolution: Code 39: 3 mil; Code 128: 3 mil; Data Matrix: 5 mil; QR Code: 5 mil
  • Electronic Article Surveillance: Compatible with Checkpoint EAS deactivation system
  • User Indicators: Good decode LEDs, rear view LEDs, beeper
  • Warranty: 3 Years

What's in the Box:

  • Zebra DS9308 Scanner Kit 2D-SR USB/STR 2M Black
  • Shielded USB Cable
  • User Manual

Ready to Use and Easy to Manage

  • The Zebra DS9308 Scanner Kit  is ready to use right out of the box with already optimised default configuration settings and auto-host detect cables. There are multiple mounting options horizontally and vertically without interrupting operations.
  • It comes with the range of value-add Zebra software tools for managing and developing applications for your DS9300 series scanner, spotting errors before any impact on productivity. With the Scanner Management Service, you can remotely manage the scanner. It has full backwards compatibility with the DS9208 cables and power supplies.

Save Time and Effort with Rapid and Accurate Scanning

  • The swipe speeds of the Zebra scanner DS9308 are nearly 50% faster than competitive scanners, and with its rapid-fire scanning capabilities it can capture barcodes as fast as they appear. It can also convert any A6 or smaller documents into electronic images, such as passports, cheques or prescriptions.
  • The scanner can accurate capture 1D and 2D barcodes, and Digimarc codes of any quality and density, including damaged, faded, low contrast, poorly printed and crinkled codes. The Multi-Code Data Formatting feature allows it to scan multiple barcodes at once while transmitting only the barcodes that are needed.

Durable and Compact to Suit Every Environment

  • The Zebra DS9308-SR scanner has excellent durability, built to withstand drops of up to 5 feet to concrete, multiple tumbles, spills and dust. The flexible scanner base has 4 positions for ready scanning while the IP52 sealing and innovative layout make it spill proof.
  • With a weight of only 318 grams, the scanner has a minimal footprint and can easily be setup wherever required, blending into the environment. The user indicators include LEDs and beeper with adjustable tone and volume.

To download the user manual for the Zebra DS9308, please click here: ds9308 manual

Manufacturer: Zebra
Scan Engine: 2D
Colour: Black
Interface: USB
Brochure: Download
